Performance data
|
| Impact rate at rated speed |
0 – 4,000 bpm |
| Rated speed |
0 – 900 rpm |
Additional data
|
| Rated input power |
800 W |
| Impact energy (according to EPTA 05/2016) |
3 J |
| Voltage, electrical |
230 V |
| Weight |
2.9 kg |
| Tool holder |
SDS plus |
Drilling range
|
| Drilling dia. concrete, hammer drill bits |
4 – 26 mm |
| Opt. appl. range concrete, hammer drill bits |
8 – 16 mm |
| Drilling diameter in concrete with core cutters |
16 mm |
Total vibration values (Hammer drilling in concrete)
|
| Vibration emission value ah |
16.5 m/s² |
| Uncertainty K |
1.5 m/s² |
Total vibration values (Chiselling in concrete)
|
| Vibration emission value ah |
10.5 m/s² |
| Uncertainty K |
1.5 m/s² |
Hammer drilling in concrete
|
| Vibration emission value ah |
16.5 m/s² |
| Uncertainty K |
1.5 m/s² |
Chiselling in concrete
|
| Vibration emission value ah |
10.5 m/s² |
| Uncertainty K |
1.5 m/s² |
The A-rated noise level of the power tool is typically as follows: Sound pressure level 91 dB(A); Sound power level 102 dB(A). Uncertainty K= 3 dB.
